4.3 Time Grid
4.3.1 Information Displayed in the Time Grid
Different color codes are used in the time grid to easily distinguish the various job types.
The color codes are the same in the Scheduler mode and in the QuickStart mode.
The following table describes the various job types with the color associated to each job
type:
Background color Meaning
Yellow
Job scheduled
Gold
(darker yellow)
Job in progress (still to be backed up)
Lime
(bright green)
Job in progress (already backed up)
Lime green
(darker green)
Job ended
Orange
Job failed
Purple
Job pending
When horizontal and/or vertical black lines are present within a job, it means that a
timecode jump has been detected. Right-clicking on the small vertical line will display the
TC value.
A job with thick hatching from left to right corresponds to an XML job.
A job with thin hatching from right to left corresponds to the selected job.
