XFile Version 2.19 – User Manual
EVS Broadcast Equipment – November 2012
Issue 2.19.A
117
4.2.3 Transfer Rate
The counter displays the current transfer rate. An average of bit-rate for all operations is
done in real-time.
4.2.4 Time
The current time is displayed on the top right of the screen. As you can select which time
information you will work with in the time grid, the time display depends on this selection.
You can select the time display to be used in the time grid in the Record Grid > Display
Mode menu.
T/C Primary: the time displayed is either the LTC or user-defined timecode type that is
displayed at the bottom the VGA and is used to work with the video material stored on a
given recorder.
LTC:
User T/C: the time displayed is the user time code of the first camera available on the
first EVS video server displayed in the grid. This time code is defined by the user on the
EVS video server.
PC time: the current time on the XStream workstation will be displayed (not the XNet
time).
XT Time Code: the time displayed is the LTC time on the first available camera of the
first EVS video server displayed in the grid. The EVS video server name and camera
name are specified with the time information.
