3.12.5 Exporting a Backup Playlist
Introduction
Exporting a playlist of backup clips from XFile will allow you to create a single media file.
This file contains a long clip that concatenates the backup clips of the playlist with cut
transitions.
The two XML files including the playlist definition and the metadata information will also
be created in the same folder.
The settings for creating and exporting the playlist are defined in the Setup menu
available from the Setup button in the PL Info area.
How to Export a Backup Playlist
Note
Before you export a backup playlist, ensure that the desired settings are
defined in the Playlist Manager Setup window. See also the section 3.12.3
‘Settings for Playlists’, on page 100.
To export a backup playlist, proceed as follows:
1.
To make the playlist available in the Playlist area, do one of the following:
• If the playlist to export already exists, load the playlist via the
button. For more information, see also the section ‘How to Load a Backup
Playlist’, on page 104.
• If the playlist to export does not exist yet, create the playlist as explained in the
section ‘How to Create a Backup Playlist’, on page 103.
2.
Click the button in the PL Info area.
The Save as dialog box opens.
3.
Select the folder where you want to export your playlist to.
4. Type a file name in the File Name field.
5. Click Save.
The backup playlist is exported to a single media file. The XML files are also created in
the same folder as the media file.
