Xedio Suite Version 4.1 - User’s Manual – Ingest Organizer
EVS Broadcast Equipment – December 2011
Issue 4.1.A
13
Menu Items Meaning
Clip Display Settings Allows to select the information to be displayed in the
encoded block :
Show Thumbnails Shows a thumbnail for the encoding block.
Refresh Refreshes the graphical interface.
About Gives information about the version of Ingest Scheduler.
CURRENT DATE
The Current Date field allows to select the date for the timeline display. This is
only available if the Nowline Focus parameter is disabled from the Parameters
menu.
3.4.2 TIMELINE CONTENT
Ingest media is displayed in the form of blocks in the timeline.
BLOCK STATUS COLORS
The block status is shown by means of different colors as follows:
Block Color Status
A blue block to the right of the nowline is a Scheduled
ingest.
A currently Recording ingest is orange.
