User Manual Owner manual
Table Of Contents
- Table of Contents
- What's New?
- 1. Introduction
- 2. User Interface
- 3. Managing Channels
- 4. Loading Media
- 4.1. Introduction
- 4.2. Possible Loading Actions
- 4.3. Loading a Train or a Recording Ingest
- 4.3.1. How to Load a Train from the Channel Explorer
- 4.3.2. How to Load a Train or a Recording Ingest from the Database Explorer
- 4.3.3. How to Select a Train or a Recording Ingest from the Panel
- 4.3.4. How to Reload the Last Loaded Train or Recording Ingest
- 4.3.5. How to Load the Source Media of a Clip
- 4.3.6. How to Load the Train from the Previous or Next Recorder Channel
- 4.3.7. How to Select a Train with the ShuttlePRO
- 4.3.8. How to Snap back to the Last Loaded Train or Recording Ingest
- 4.4. Loading a Clip
- 4.5. Loading a Playlist
- 4.6. Loading a Timeline
- 4.7. Loading a Media with the Take Function in PGM/PRV Mode
- 5. Moving through Media
- 6. Creating Media
- 7. Editing Media
- 8. Publishing a Clip
- 9. Transferring Media
- 10. Exporting and Importing Playlists
- 11. Settings
- 12. Control Panel Shortcuts
Operation
User Interface
Button
Keyboard
Shortcut
ShuttlePRO key Description
Mark IN Sets an IN point
at the timecode
shown in the
Current
Timecode field
and corresponding
to the bullet
indicator position
on the jog bar.
Then, a green
indicator
represents the IN
point on the jog
bar.
Mark
OUT
Sets an OUT
point at the
timecode shown
in the Current
Timecode field
and corresponding
to the bullet
indicator position
on the jog bar.
Then, a red
indicator
represents the
OUT point on the
jog bar.
Clear IN
+
+
Clears the IN
point which has
just been set and
not yet saved.
When applied to a
loaded clip, the
INpoint is set to
the Protect IN
timecode, before
the guardband.
78 6. Creating Media
EVS Broadcast Equipment S.A. - June 2013 Issue 6.2.A
