Operation
User
Interface
Button
Keyboard
Shortcut
ShuttlePRO
key
Description
If the button is clicked twice, the
next 2 elements will be skipped,
and so on.
5.3. Jumping to a Given Timecode within
the Loaded Media
There are several ways to jump to a given timecode within a loaded media:
• Click at one position on the jog bar
• Click on the bullet indicator and move it along the jog bar
• Enter a new timecode value in the Current Timecode field and press ENTER.
Note
If the player channel is ganged with others, the same operation is performed on
all the ganged channels.
5.4. Playing Media at a Custom Speed
5.4.1. Context of Use
This function can be used when the following element types are loaded on a channel,
would it be cued, paused, or being played out:
• Clip
• Growing clip
• Train
• Playlist element
It can also be used if the channel is part of a
• Gang group: the speed is applied to all the channels of the group at the same time.
• Fill & Key association: the speed is applied to all the channels of the group at the
same time.
• PGM/PRV association: the speed is only applied to the PGM channel.
74 5. Moving through Media
EVS Broadcast Equipment S.A. - June 2013 Issue 6.2.A
