User Manual Owner manual
Table Of Contents
- Table of Contents
- What's New?
- 1. Introduction
- 2. User Interface
- 3. Managing Channels
- 4. Loading Media
- 4.1. Introduction
- 4.2. Possible Loading Actions
- 4.3. Loading a Train or a Recording Ingest
- 4.3.1. How to Load a Train from the Channel Explorer
- 4.3.2. How to Load a Train or a Recording Ingest from the Database Explorer
- 4.3.3. How to Select a Train or a Recording Ingest from the Panel
- 4.3.4. How to Reload the Last Loaded Train or Recording Ingest
- 4.3.5. How to Load the Source Media of a Clip
- 4.3.6. How to Load the Train from the Previous or Next Recorder Channel
- 4.3.7. How to Select a Train with the ShuttlePRO
- 4.3.8. How to Snap back to the Last Loaded Train or Recording Ingest
- 4.4. Loading a Clip
- 4.5. Loading a Playlist
- 4.6. Loading a Timeline
- 4.7. Loading a Media with the Take Function in PGM/PRV Mode
- 5. Moving through Media
- 6. Creating Media
- 7. Editing Media
- 8. Publishing a Clip
- 9. Transferring Media
- 10. Exporting and Importing Playlists
- 11. Settings
- 12. Control Panel Shortcuts
2. Load a playlist on the Clip-List tab.
3. Drag an element from the playlist onto the Loaded Media field.
The element will then be loaded on the Control Panel.
The Player field background turns turquoise to highlight this situation.
4.6. Loading a Timeline
4.6.1. How to Load a Timeline from the Database
Explorer
To load the timeline, proceed as follows:
1. Open the Control Panel and assign a player channel or the Software Player.
2. Open the Database Explorer from the main menu.
3. In the Timelines view of the Database Explorer, select the requested timeline in the
Elements grid.
4. Drag it onto the Loaded Media field of the Control Panel.
The timeline will then be loaded on the IN point of the first element.
The IPEdit mode (also called Lock Timeline mode) is automatically activated.
If the channel does not support the "Mix on one channel" functionality, this is highlighted
as follows:
Then, two player channels are set to Timeline mode to enable the effects between
timeline elements to be played out.
If the channel supports the "Mix on one channel" functionality, this is highlighted as
follows:
Then, effects between timeline elements can be played on one channel.
IPDirector- Version 6.2- User Manual- Control Panel
4. Loading Media 67
