4.4. Loading a Clip
4.4.1. How to Load a Clip or a Recording Ingest
from the Control Panel
To load a clip or a recording ingest on a player channel or the Software Player from the
Control Panel interface, proceed in one of the following ways:
• Enter the clip name in the Loaded Media field of the Control panel and press Enter.
• Enter the clip LSM ID in the LSM ID field and press Enter.
• Click the arrow next to the Last Created Clips field and select a clip from the list.
• When a clip has already been loaded during the current session, it is listed in the list
available from the Loaded Media field. Click the arrow next to the Loaded Media
field and select a clip from the list. This list contains the last 20 clips or trains that you
have loaded on the channel during the current session.
4.4.2. How to Load a Clip from the Database
Explorer
To load a clip on a channel from the Database Explorer, proceed as follows:
1. Open the Control Panel and assign a player channel or the Software Player.
2. Open the Database Explorer from the main menu.
3. In the Clips view or Clip Elements view of the Database Explorer, select the
requested clip in the Elements grid.
