4.3.6. How to Load the Train from the Previous or
Next Recorder Channel
When a train is loaded, it is possible to load a train from the previous or next recorder
channel thanks to the ShuttlePRO keys:
Operation
User Interface
Button
Keyboard
Shortcut
ShuttlePRO key
Previous
Recorder
- -
Next Recorder - -
Two situations can occur:
• The recorder channel currently selected does not belong to a group of ganged recorder
channels, then the next or previous record train of the XNet network is loaded.
• The recorder channel currently selected belongs to a group of ganged recorder
channels, then the next or previous record train of the group is loaded .
4.3.7. How to Select a Train with the ShuttlePRO
Prerequisite
The same player must have been associated to the Control Panel and selected from the
ShuttlePRO.
Procedure
To select a train with the ShuttlePRO, proceed as follows:
1. Press the Select Train key .
60 4. Loading Media
EVS Broadcast Equipment S.A. - June 2013 Issue 6.2.A
