Selecting a recorder channel loads the corresponding train at its current recording position
and plays it on the selected player. The E/E button turns blue only when a train is loaded
and playing live.
Selecting a recording ingest directly loads it at its currently recording position (OUT point)
and plays it on the selected player.
Note
If a recorder channel is connected to an OUT port of a video router, itself
associated to an INport, the name of the router INport is displayed after the
recorder channel name.
How to Select a Train from the Loaded Media Field
When a train or a recording ingest has already been loaded during the current session, it is
listed in the list available from the Loaded Media field. This list shows the last 20 items
that you have loaded on the channel during the current session.
Click the arrow next to the Loaded Media field and select an item from the list:
4.3.4. How to Reload the Last Loaded Train or
Recording Ingest
If a clip or a playlist element is loaded on a player channel or the Software Player, clicking
the E/E button will unload it and load and play the last loaded media (record train or
recording ingest) at its current recording position.
The text below the E/E button indicates the media (train or recording ingest) which will be
loaded on the player channel when the E/E button is clicked:
Note
In case the previously recording ingest is finished when the E/E button is
clicked, the recorded clip is loaded on its IN point and stays in pause. If this clip
has been deleted, nothing happens.
