User Manual Owner manual
Table Of Contents
- Table of Contents
- What's New?
- 1. Introduction
- 2. User Interface
- 3. Managing Channels
- 4. Loading Media
- 4.1. Introduction
- 4.2. Possible Loading Actions
- 4.3. Loading a Train or a Recording Ingest
- 4.3.1. How to Load a Train from the Channel Explorer
- 4.3.2. How to Load a Train or a Recording Ingest from the Database Explorer
- 4.3.3. How to Select a Train or a Recording Ingest from the Panel
- 4.3.4. How to Reload the Last Loaded Train or Recording Ingest
- 4.3.5. How to Load the Source Media of a Clip
- 4.3.6. How to Load the Train from the Previous or Next Recorder Channel
- 4.3.7. How to Select a Train with the ShuttlePRO
- 4.3.8. How to Snap back to the Last Loaded Train or Recording Ingest
- 4.4. Loading a Clip
- 4.5. Loading a Playlist
- 4.6. Loading a Timeline
- 4.7. Loading a Media with the Take Function in PGM/PRV Mode
- 5. Moving through Media
- 6. Creating Media
- 7. Editing Media
- 8. Publishing a Clip
- 9. Transferring Media
- 10. Exporting and Importing Playlists
- 11. Settings
- 12. Control Panel Shortcuts
Timelines
When the channel
mode is set to…
and the "Mix on one
channel" functionality
…
then, a loaded timeline will be
played
1PGM is supported with the transition effects. The IPEdit
mode is enabled on that channel.
1PGM is not supported with the transition effects. The IPEdit
mode is enabled on a pair of
channels.
3.7. Managing Ganged Player Channels
3.7.1. Introduction
When the player channel associated to the Control Panel is part of a group of ganged
channels, all the channels from the group are listed in the Ganged Channels tab of the
Control Panel.
Several operations can be performed from this tab.
3.7.2. How to Temporarily Ungang and Re-Gang
Some Channels
Unganging Channels
You can temporarily ungang some of the player channels from a group of ganged
channels.
To do so, proceed as follows:
1. Click the Ganged Channels tab to display the list of player channels ganged to the one
currently assigned to the Control Panel.
48 3. Managing Channels
EVS Broadcast Equipment S.A. - June 2013 Issue 6.2.A
