When the "Mix on one channel" functionality is not supported, the timeline must be loaded
on an odd player channel (PGM1 or PGM3) to be played with its transition effects. The
IPEdit mode can be manually enabled from the Channel Explorer or automatically by
loading a timeline on an odd channel controlled from a Control Panel. The mode is
mentioned in the title bar of the Control Panel.
To be able to load another element on one of these player channels, they must first be
manually unganged from the Channel Explorer.
3.6.3. Limitations for the Mix on One Channel
Functionality
A player channel will not support the "Mix on one channel" functionality in one of the
following cases:
• It is on a COHX board on the EVS video server
• It is a 1080p channel
• It is a 3D channel
• It is a 3G input
• It is on a V3X board on the EVS video server but the "Mix on One Channel" parameter
is set to No on the Server Configuration screen.
3.6.4. Summary
This section summarizes the resulting actions when playing a playlist or a timeline,
depending on the channel mode and the channel types
Playlists
When the channel
mode is set to…
and the "Mix on one
channel" functionality
…
then, a loaded playlist will be
played
1PGM is supported with the transition effects
PGM/PRV is not supported with the transition effects
1PGM is not supported without the transition effects (Cut
mode)
