You can press the key to switch from one mode to another.
2.4.5. Remaining Time / Capacity Field
This field will have a different meaning and display color according to the activity being
performed on the channel.
When a clip is loaded
The following table shows the possible colors and meanings of the Remaining Time /
Capacity field when a clip is loaded.
The Remaining Time / Capacity field value and color depends on:
• whether the clip is playing or paused
• the media position indicator.
• the defined (mark) IN and (mark) OUT points:
◦ When no new mark IN and mark OUT have been defined after the clip has been
loaded, the values displayed are based on the original IN and OUT points of the
clip.
◦ When a new mark IN and/or mark OUT have been defined after the clip has been
loaded, the values displayed will be based on this new mark IN and/or mark OUT
point(s).
Play/Pause Position Indicator Timecode Value Color
Pause On or between IN
and OUT points
Count down to the OUT point White
Pause Before IN point Count down to the IN point White
Pause After OUT point Duration from the OUT point Grey
Play On or between IN
and OUT points
Count down to the OUT point Yellow
Play Before IN point Count down of the remaining time to
the OUT point
White
Play After OUT point Count down of the remaining time to
the end of guardband (Protect OUT
point)
White
When a record train is loaded
The following table shows the possible colors and meanings of the Remaining Time /
Capacity field when a train is loaded.
