Option Description
See section "How to Publish a Clip to a User Group" on page 91.
View Key
Clip
Displays the Key clip associated with a Fill clip that is loaded.
Unlink Deletes the link between the Fill and Key clips or between ganged clips.
Rename Opens the Update Clip Name window from which the clip name can be
modified.
Modify TC
IN or Date
Opens the Modify TC In or Date window from which you can modify the
timecode or date of the IN point of the loaded clip.
Protect Protects the loaded clip, which means that users will receive a warning
when they try to delete a protected clip in IPDirector or in Multicam.
Unprotect Unprotects the loaded clip when it has been protected earlier in
IPDirector.
Duplicate Opens the Duplicate Clip window where you can specify the location
(LSM ID) on an EVS video server of the XNet Network where a copy of
the clip should be stored.
Move Opens the Move Clip window where you can specify the location on an
EVS video server of the XNet Network where the clip should be moved
to.
Show/Hide
Video
Display
Shows the Video Display inside the Control Panel when it is off or hides
it when it is on. If the Video Display is not linked to the player channel,
the option is not available.
2.4. Transport Functions Pane
2.4.1. Introduction
The Transport Functions pane provides a jog bar and more transport functions to navigate
in the loaded element.
