Menu Item Description
Software Player Links the Software Player to the Control Panel.
2ND Controller Passes the control of the player on to the secondary controller,
if any.
See section "Controlling the Player from a Secondary
Controller" on page 44.
Mode Allows the users to choose the operation mode of the selected
player channel. A sub-menu provides two options: 1PGM,
PGM/PRV.
See section "Playing a Series of Clips or a Playlist" on page
45.
ON AIR Sets the player channel to ON AIR Status.
See section "Enabling the On-Air Feature" on page 42.
Set Channel to
IDLE
Sets the channel to IDLE.
None Removes the association between the Control Panel and the
player.
Workstation
Channel
Links the Control Panel to the player channel set as linked in
the IPDirector Configuration window of the Remote Installer.
[List of player
channels from
available EVS
video servers]
Provides the list of player channels available on the XNet
network, and visible to the current user, which can be assigned
to the Control Panel.
See section "Assigning a Player" on page 38.
When a player channel is connected to an IN port of a video
router, itself associated to OUTports, the name of the router
OUTport(s) is displayed after the player channel name.
2.3.4. Loaded Media Field
This field displays the name of the clip, file, playlist element or record train that is loaded
on the player.
This field also provides a drop-down list that contains the last 20 clips or trains that you
have loaded on the channel during the current session. The drop-down list displays the
most recently loaded clips at the top and it displays the loaded media only once in the list,
even if loaded several times by the user.
See section "Loading Media" on page 54 for more information on how to load media.
2.3.5. Element Types
An Element Type icon is displayed on the left of the Loaded Media field. It reflects the
element loaded on the player.
The following icons can be displayed:
14 2. User Interface
