Channel Mode
Title bar / window frame
color
Focus ON the window (=Window active) Blue
Focus OFF the window (=Window not active) and
• no channel associated to the Control Panel
Black
Focus OFF and
• channel associated to the Control Panel and
• channel not ganged and
• no playlist element loaded on the Control Panel
Black
Focus OFF and
• channel associated to the Control Panel and
• channel ganged to another one and
• no playlist element loaded on the Control Panel
Green
Focus OFF and
• playlist element loaded on a Control Panel for
editing purposes
(regardless of ganged or not)
Turquoise
2.1.3. Channel Mode Display
The window title bar gives information such as the association type or the channel mode
in which the controlled player channel is involved or the "Mix on one channel"
functionality.
Display Meaning
Channel not
supporting "Mix on
one channel" and
involved in no
association
(previously called
1PGM)
PGM or PRV Channels
