Click the VTR button to display the VTR View and see the available VTR devices.
From the VTR view, you can perform the following operations:
• locking a VTR device
• opening a VTR Control Panel by right-clicking a VTR name and selecting the
appropriate option from the contextual menu.
2.6. Contextual Menus
Contextual menus are available when right-clicking an EVSvideo server, a recorder
channel, a stream or a player channel.
The following table list all the options for an EVSvideo server and the sections where they
are described:
Option See section...
Show Server
Monitoring Info
"How to Get Server Monitoring Information" on page 35
Restart Server... "How to Launch a Different Predefined Server
Configuration" on page 35.
Configure Server... "Multicam Web Setup Tool" on page 37.
The following table describes all the options for a recorder channel:
Option See section...
Open Recorder Panel "Assigning a Recorder Channel" on page 15.
Open Ingest Scheduler
(new ingest)
"How to Start or Stop a Server Ingest" on page 31.
Start XTIngest "How to Start or Stop a Server Ingest" on page 31.
Stop XTIngest "How to Start or Stop a Server Ingest" on page 31.
Lock "Locking a Channel" on page 16.
IPDirector- Version 6.2- User Manual- Channel Explorer
2. User Interface 11
