If no network is defined in Remote Installer, there will be no XNet root and the EVS
servers will appear as root nodes.
A lot of information is given, by means of icons or additional text, on the hardware/device,
type of server channel, resolution, connected remote devices, stream status, channels
association mode... See section "Channel Explorer Icons" on page 5 for a description of
all the icons.
2.2. Channel Explorer Icons
A lot of information is given in the Channel Explorer window, by means of icons or
additional text, on the hardware/device, type of server channel, resolution, connected
remote devices, stream status, channels association mode,...
The meaning of each icon is explained in the following tables.
Resolution Information
Icon Description
high resolution XNet
low resolution XNet
Hardware
Icon Description
EVS video server connected to the XNet. The XT label is used for any type of
EVS๎video server.
VTR device connected to the XNet
XF device connected to the XNet
