IPDirector Version 5.9
–
User Manual
–
Part 3: Browsing
EVS Broadcast Equipment – January 2011
Issue 5.9.B
83
9. Logs View
9.1 INTRODUCTION
The logs section of the Database Explorer allows you to browse for logs of any
event for which a log has been created. Then you can use the search features to
filter the data.
Logs are displayed in the Database Explorer grid with the highlighted color which
has been associated to the log at creation in IPLogger.
The log view can be expanded thanks to a small arrow at the beginning of
each line in the grid to display log entries, Protect Media clips and associated
clips.
Refer to the chapter on IPLogger in part 2 of the user manual for more
information.
9.2 LOGS TREE STRUCTURE
You can build and customize the Logs tree structure, by adding and organizing
directories.
The Logs tree structure displays directories you may have created as well as the
log sheets which have been created with IPLogger.
You can take advantage of the log directories by searching all log sheets
contained inside the directory. This allows a search across a range of log sheets
instead of all sheets in the system.
Note
If you have selected a directory in the logs tree structure, the system will
disable the Automatic Refresh option for the time being. This is to
minimize wasteful database query updates on the browser window.
