User's Manual Instruction Manual
Table Of Contents
- Copyright
- Disclaimer
- Improvement Requests
- Regional Contacts
- User Manuals on EVS Website
- 1. Introduction
- 2. User Interface
- 2.1 OPENING OF DATABASE EXPLORER
- 2.2 OVERVIEW OF THE DATABASE EXPLORER
- 2.3 DATABASE EXPLORER TOOLBAR
- 2.4 TREE VIEW
- 2.5 ELEMENT GRID AND SEARCH OPTIONS
- 2.6 STATUS BAR
- Clips, Clip Elements and Nearline Files
- 4. Clips View
- 4.1 INTRODUCTION
- 4.2 UNDERSTANDING CLIP STRUCTURE ON AN EVS VIDEO SERVER
- 4.3 VIRTUAL LSM ID / REAL LSM ID
- 4.4 CLIP TREE STRUCTURE
- 4.5 CLIP DATA COLUMNS
- 4.6 CLIP CONTEXTUAL MENU
- 4.7 DELETING A CLIP
- 4.8 EDITING A CLIP
- 4.9 COPYING OR MOVING A CLIP
- 4.10 SENDING A CLIP TO A DESTINATION TARGET
- 4.10.1 Send To Menu
- 4.10.2 How to Send a Clip to the Default Archive
- 4.10.3 How to Send a Clip to a Destination Folder (Destination Target)
- 4.10.4 How to Add a Destination Target
- 4.10.5 How to Delete a Destination Target
- 4.10.6 How to Send a Clip to an XStore Workstation (Running CleanEdit Applications)
- 4.10.7 How to Send a Clip to an Avid System Using the AVID Transfer Manager
- 4.10.8 Transfer Monitoring
- 4.11 HOW TO MODIFY THE T/C IN OR THE DATE OF A CLIP
- 4.12 PUBLISHING A CLIP
- 4.13 LINKING CLIPS
- 5. Clip Elements View
- 6. Playlists View
- 7. Timelines View
- 8. Bins View
- 9. Logs View
- 9.1 INTRODUCTION
- 9.2 LOGS TREE STRUCTURE
- 9.3 HOW TO CREATE A LOGS DIRECTORY
- 9.4 HOW TO RENAME A LOGS DIRECTORY
- 9.5 HOW TO DELETE A LOGS DIRECTORY
- 9.6 HOW TO PUBLISH A LOG DIRECTORY OR A LOG SHEET
- 9.7 HOW TO VIEW THE LOG DIRECTORY OR LOG SHEET PROPERTIES
- 9.8 HOW TO DELETE A LOG DIRECTORY OR A LOG SHEET
- 9.9 HOW TO EXPORT A LOG SHEET FROM THE TREE
- 9.10 HOW TO EXPORT A LOGGING PROFILE FROM THE TREE
- 9.11 PRINTING A LOG SHEET
- 9.12 LOG EVENT COLUMNS
- 10. Media Files View
- 11. Searching the Database
- 12. Loading and Playing Media from the Database Explorer
- 13. Database Explorer Shortcuts
Issue 5.9.B IPDirector Version 5.9
–
User Manual
–
Part 3
–
Browsing
EVS Broadcast Equipment – January 2011
66
Command Description
file, after setting up the requested TC for the track.
For more information, see section “How to Export a
Playlist” in the Playlist Panel chapter, in part 6 of the user
manual.
Publish Opens the Publish Playlist window in which you can specify
the user groups the selected playlist should be published
to.
The playlist will be published to the selected groups
providing that they have the adequate rights.
Edit/Rename Opens the Edit a Playlist window in which you can modify
the playlist properties as entered when the playlist was
created.
Regenerate T/C
Output
Allows generating a continuous timecode to be able to
browse a playlist easily.
Delete playlist Deletes the playlist from the EVS video server. This does
not delete the related clips.
Delete all unused
playlists
Opens the Delete Unused Playlists window from which you
can select a reference date for the deletion of playlists.
All the playlists (on all the EVS video servers of the XNet
network) not used since the reference date will be
displayed in the window. All the retrieved playlists or a
selection of them can be deleted.
For more information, see section ‘How to Delete Unused
Playlists’ in the Playlist Editor chapter, in part 6 of the
user manual.
Set as default
playlist
Allows you to set the selected playlist as default playlist.
Create an off-line
copy
Creates a new off-line playlist.
This new off-line playlist has the same content as the
playlist selected.
Copy/Move Playlist This allows the users to:
• create an off-line or on-line copy of the open playlist
• move the playlist to another EVS server
• make the playlist off-line.
Refer to section ‘Copying and Moving a Playlist’ in part 6
of the user manual for more information.
Link Allows you to link the selected playlists together.
Unlink Allows you to unlink the playlists linked to the selected
playlists.
