IPDirector Version 5.9
–
User Manual
–
Part 3: Browsing
EVS Broadcast Equipment – January 2011
Issue 5.9.B
59
Column Name Description
• EVS video server for XT clips
• for nearline defined in the configuration menu: nearline
directory for files
• for detected IP drives: ‘drive name’ on ‘machine name’.
Storage of off-line clip elements are included if Show
offline files is enabled.
Master This information is only for files. The column is empty for
clips.
The master file is the first file created for a clip element
and detected on the nearline. The master column indicates
YES.
When shorter clips, are created from a file, they receive
the flag NO in the Master column.
Full Path Only for files.
File Name Only for files.
Cam Pref. Displays a preference value that is generated when clips
are created from an LSM control panel
Nb Audio Tracks How many audio tracks the clip has.
Video Format Shows the video format of the clip:
PAL SD 625i, PAL HD 1080i, NTSC HD 1080i, …
Video Codec Shows the video codec of the clip:
DNxHD, MPEG2 i-frame,…
Video Bitrate Shows the video bitrate of the clip: from 20 to 360.
Aspect Ratio 4:3 Letter Box, 4:3 Box, or 16:9
VBI This has a value when the clip contains information within
the picture such as teletext, VITC or other such data
needed by graphics applications.
Audio Type Mono, Stereo, Dual Stereo, 8 tracks.
