IPDirector Version 5.9
–
User Manual
–
Part 3: Browsing
EVS Broadcast Equipment – January 2011
Issue 5.9.B
49
Once the clip has been sent, it is immediately available in the CleanEdit database.
It can then be inserted into a project, edited or played out using Playout Organizer
or CleanPlayout Server.
Note
Which clip elements will be sent depends on the target: you can
configure hi-res targets, lo-res targets or hi/lo targets.
Required Configuration
These destination targets are defined from the IPDirector Remote Installer and a
corresponding XFile XML unit must have been correctly configured. The name
used to define the type of transfer is user-definable and may be different from the
CleanEdit target used in the screenshot above. Refer to the IPDirector Remote
Installer and XFile user manual for more information.
4.10.7 HOW TO SEND A CLIP TO AN AVID SYSTEM USING THE AVID
TRANSFER MANAGER
To send a clip to an Avid system using the Transfer Manager, proceed as follows:
1. Right-click the clip line or XT clip line corresponding to the clip you want to
send to Avid.
The clip contextual menu is displayed.
2. Select Send To from the clip contextual menu and select a predefined Avid
TM target from the Send To > Avid sub menu.
