IPDirector Version 5.9
–
User Manual
–
Part 3: Browsing
EVS Broadcast Equipment – January 2011
Issue 5.9.B
47
NEW ARCHIVE TARGET WINDOW
The New Archive Target window makes it possible to add a new destination or
archive target. The fields displayed on the New Archive Target Window are
described below:
Field Description
Target Name The name of the target as it will appear in the contextual
menu.
Backup
Destination
Directory
The destination folder where the file will be copied. Be sure
this directory is shared with full control access.
File Format The file format. It can be MXF EVS, MXF OP1A, QuickTime
Movie, or QuickTime Reference, MXF OPAtom, AVI.
XML Unit Drop-down list with the available XML Units, as defined in the
Remote Installer, which could manage all the files sent to the
destination target.
Generate XML
Metadata file
When this check-box is selected, an XML file with the metadata
of the clips backed up is generated. This file is created at the
same time as the backup file for all media file formats. In the
MXF EVS format, the metadata is included in the media file
itself.
XML Metadata
file path
The destination folder where the XML Metadata file will be
stored.
