Issue 5.9.B IPDirector Version 5.9
–
User Manual
–
Part 3
–
Browsing
EVS Broadcast Equipment – January 2011
38
4.8 EDITING A CLIP
4.8.1 HOW TO EDIT A CLIP FROM WITHIN THE DATABASE
EXPLORER
To edit the clip data, proceed as follows:
1. Select the clip or a clip element.
2. Right-click and select Edit.
The Edit Clip window appears offering the ability to add or change clip data. For
more information on the Edit Clip window, refer to section “Edit Clip Window”
be
low.
4.8.2 EDIT CLIP WINDOW
In the Edit Clip window you can add or change clip data. It is accessible from the
clip contextual menu in the Database Explorer.
Changes are applied to all elements in the same clip, since all elements share the
same metadata.
WINDOW OVERVIEW
The Edit Clip window is divided into two panes:
• The left pane contains metadata in general and in relation with IPDirector.
It is always displayed.
• The right pane contains metadata based on profiles.
Clicking the right area in the Pane Display icon will display this right
pane.
FIELDS IN THE EDIT CLIP WINDOW
The fields displayed on the Edit Clip Window are described below:
