IPDirector Version 5.9
–
User Manual
–
Part 3: Browsing
EVS Broadcast Equipment – January 2011
Issue 5.9.B
35
Command Description
For information on the option ‘delete clip if present in a
playlist or timeline’, refer to section 4.7 ‘Deleting a Clip’
o
n page 37.
View Key Clip Displays the Key clip associated with a Fill clip that is
selected. This option is only active for Fill clips that are
included in a Fill and Key association.
Edit Opens the Edit Clip window from which the user can
modify the clip information. Metadata is common between
all clip elements.
See also section 4.8.2 ‘Edit Clip Window’ on page 38.
Modify T/C IN or
Date
Opens the Modify T/C In or Date window from which the
user can modify the IN timecode or date of the clip.
See also section 4.11 ‘How to Modify the T/C in or the
D
ate of a Clip’ on page 52.
Generate XML
Metadata
The XML file is synchronized for the selected clip or clip
element, provided that the IP workstation has been
configured as master. With workstations configured as
slave, an error message is displayed when using this
option.
Protect Allows you to protect or unprotect a clip from deletion:
• A green Protect icon appears in the Protect column
of the element list when the clip is protected by the
IPDirector protocol.
