IPDirector Version 5.9
–
User Manual
–
Part 3: Browsing
EVS Broadcast Equipment – January 2011
Issue 5.9.B
33
Note
When you protect a XT hi-res clip, the lo-res version (if present) is
protected automatically and vice versa. Then, two icons will be
displayed, one for each XT clip. The protect feature does not affect hi-
res or lo-res files.
If a clip is protected by the IPDirector protocol, a green Protect icon appears
in the Protect column of the element.
If the clip is protected by another protocol, a red Protect icon appears in the
Protect column.
Note
It is possible to protect a clip via IPDirector if it is already protected by
another protocol. This will ensure that the clip remains protected even if
it is unprotected later by the other protocol.
In IPDirector, it is not possible to remove the clip protection defined by
another protocol.
4.6 CLIP CONTEXTUAL MENU
The Clip Contextual menu is available when right-clicking a clip in the element
list. It gives access to the actions that can be performed on clips in the Database
Explorer.
Note
No contextual menu is available from a record train.
The following table describes the commands in the clip contextual menu:
Command Description
Cut Not relevant in the element list.
Copy Copies the clip to the clipboard. A shortcut to the clip can
then be pasted in a bin.
Paste Not relevant in the element list.
Send To Provides a list of possible destinations to which the
selected clip can be sent.
Possible destinations are:
• the user’s default bin
• the user’s default playlist
• a default archive target
