Issue 5.9.B IPDirector Version 5.9
–
User Manual
–
Part 3
–
Browsing
EVS Broadcast Equipment – January 2011
24
Error Message Source of the Error
Bad data in one or more metadata
tag
Bad metadata file: bad/incoherent data
(e.g. IN < OUT, bad value).
Unsupported A/V format. You need to
transcode your file before importing
it to IPDirector nearline.
Unsupported A/V format (recognized
by Timecode Extractor but not
supported natively).
Could not read A/V file. This file
might be corrupted or in the wrong
format.
Corrupted A/V file. Timecode Extractor
or EVS MXF.dll cannot read the file.
3.3.2 SUPPORTED CODECS
The following codecs can be managed by the nearline:
• SD: MJPEG SD, MJPEG Proxy, IMX 30, IMX 40, IMX 50, DVCPRO 25,
DVCPRO 50, MPEG-1, MPEG-2, MPEG-2 (I-Field), DV25, H-264.
• HD: MJPEG EVS HD, MJPEG Standard HD, MPEG-2, MPEG-2 (I-Field), MPEG-
2 HD (I-frame), Avid DNxHD® Lo, DNxHD® Hi 8 bits, DNxHD® Hi 10 bits,
DVCPRO HD 100 mbps, XDCAM HD, ProRes 422 SQ, ProRes 422 HQ, ProRes
422 LT, AVC Intra, H-264, AVC Intra 50, AVC Intra 100.
3.3.3 OFF-LINE NEARLINE FILES
Off-line files are displayed in the Database Explorer when the Show off-line files
option is selected from the List View menu available on the toolbar.
DISPLAY OF OFF-LINE CLIPS OR CLIP ELEMENTS
All off-line clips / clip elements are displayed in italic.
A clip is off-line when all its clip elements are off-line.
For example
: a clip which contains an off-line hi-res file and an on-line lo-res XT
clip will be on-line, even for ‘hi-res only’ browsers.
OPERATIONS ON OFF-LINE CLIP OR CLIP ELEMENTS
The following operations are not allowed on off-line clips or clip elements:
• left-click
• right-click
• drag-and-drop
• double-click
• assign mode
• modify assigned keywords
• browse mode
