Issue 5.9.B IPDirector Version 5.9
–
User Manual
–
Part 3
–
Browsing
EVS Broadcast Equipment – January 2011
18
4. If you wish to change the display order of a column, you can drag it to a
different position in the Visible Columns pane.
5. Click OK to confirm or Cancel to exit without applying the changes.
How to Remove Columns from the Element List
To remove columns from the element list, proceed as follows:
1. Right-click a column header and select Organize.
2. The Select Columns window opens:
3. To select the column(s) you wish to remove from the view, do one of the
following:
• double-click the column(s) you wish to remove from the view on the right
pane
OR
• select them in the Visible Columns area on the right pane and press the
left blue arrow
OR
• drag them onto the ‘() Columns’ area.
Use CTRL + click to select multiple columns.
Use SHIFT + click to select a range of columns.
4. Click OK to confirm or Cancel to exit without applying the changes.
Save Grid Organization
When the user save the grid organization from a bin or from the main tree view of
a Database Explorer, the same grid organization will be applied to:
• the Clips tree and the Clip view in bins
• the Playlists tree and the Playlists view in bins
• the Timelines tree and the Timelines view in bins
Different grid organizations may be applied to different Database Explorer
windows.
