Issue 5.9.B IPDirector Version 5.9
–
User Manual
–
Part 3
–
Browsing
EVS Broadcast Equipment – January 2011
6
Options related to
the element list
display
Description
Fill Key Displays a simple list of Fill & Key elements.
Multiline List with
Thumbnails
Displays related information in columns with some
parameters displayed on several lines.
Also shows a thumbnail associated to the elements.
Thumbnails View Displays a larger version of the thumbnails.
Note
Thumbnails can be created automatically when there is an XFile or an
XTAccess designated within the thumbnails configuration in the Remote
Installer application of IPDirector. Refer to the Technical Reference
manual for further details.
Thumbnails can be created manually from the Control Panel (refer to
section about Grab Thumbnail button in part 5 of the manual) and from
the Database Explorer (refer to section ‘Photo Button’ on page 7).
2.3.2 PRINT BUTTON
Clicking the Print button opens the Print Log Sheet window from which you can
print the element list currently displayed in the grid.
2.3.3 BROWSE AND PLAY OPTIONS
These browse and play options allow you to:
• automatically load an element on a player channel, ready to play
• automatically play an element on a player channel
• automatically play a list of elements
as they are selected in the Database Explorer.
Details are described below.
Note
These options can only be used when a channel is assigned to the
Database Explorer. Refer to section 12.1 ‘How to Assign a Player
C
hannel to the Database Explorer’ on page 113.
