IPDirector Version 5.9
–
User Manual
–
Part 3: Browsing
EVS Broadcast Equipment – January 2011
Issue 5.9.B
115
Note
Nothing happens when trying to browse an off-line file.
12.2.2 ON THE PLAYER CHANNEL ASSOCIATED TO THE CONTROL
PANEL
As explained in the chapter describing the Control Panel module, it is possible to
load media from the Database Explorer to the Control Panel by a drag-and-drop
operation. This does not require the association of a player channel to the
Database Explorer. The media is then loaded on the player channel assigned to
the Control Panel.
Note
At that point, you will have the possibility to play the media by
• pressing the Play shortcut key to play the element
OR
• pressing the Play button on the Control Panel if the channel assigned
to the Database Explorer is also assigned to an opened control panel.
12.3 PLAYING MEDIA
There are several ways available to play media on a channel from the Database
Explorer:
• Load as explained in section 12.2 ‘Loading media’ on page 114 and play by
clicking the shortcut key or the Play button on the Control Panel.
• Immediately play on the channel assigned to the Database Explorer
• Immediately play on the channel assigned to the Control Panel
Note
Nothing happens when trying to play an off-line file.
