IPDirector Version 5.9
–
User Manual
–
Part 3: Browsing
EVS Broadcast Equipment – January 2011
Issue 5.9.B
107
From the Database Explorer, it is thereafter possible to retrieve the media linked
to all the child keywords of the same parent keyword by using the recursive
option.
To do so, proceed as follows:
1. In the Database Explorer, select the tree branch you wish to perform a
search on.
2. In the grid, show the columns you wish to perform a search on.
3. Display the Grid Filter bar by clicking the Show/Hide Grid Filter Bar button
over the grid.
4.
Click the Complex Filter button displayed in the Keywords column
header.
The Select Filter Condition (Keywords) window opens.
5. In the Dictionaries field, select the dictionary name.
The keywords from the selected dictionary are displayed in the list.
6. Select the parent keyword on which you want to perform a search.
It is displayed in the Keywords Condition field.
7. Select Recursive in the checkbox to perform a search on all the child
keywords linked to the selected parent keyword.
8. Press OK.
The list of elements containing a child keyword of the selected parent keyword is
displayed in the Database Explorer grid.
