Issue 5.9.B IPDirector Version 5.9
–
User Manual
–
Part 3
–
Browsing
EVS Broadcast Equipment – January 2011
102
For search in free text fields
:
4. Click inside one of the grid filter fields.
5. Enter a search value, based on the free text grid filter rules detailed in
section ‘Grid Filter Rules’ on page 101.
6.
Press ENTER to apply the filter or proceed to another field.
For search in non-free text fields:
The Complex Filter button is displayed to the right of many of the Grid Filter
fields.
Click the button to select specific search values.
Below are some examples:
Grid Filter Field Complex Filter Entry Window
Option List Click the Complex Filter button next to a combo box to open
the entry window with the option list for the combo box.
Select one or more options.
Confirm your selection with the OK button:
Or cancel and exit by clicking the Cancel button:
