IPDirector Version 5.9
–
User Manual
–
Part 3: Browsing
EVS Broadcast Equipment – January 2011
Issue 5.9.B
101
11.5.1 SEARCH FIELDS TYPES
Different types of search fields exist:
• free text fields: no button is available next to the field, e.g. Name field.
• field with an option list : the button is displayed on the right of the
field, e.g. Level field.
• field with a complex filter button on the right of the field giving access
to a Select Filter Condition window.
11.5.2 GRID FILTER RULES
The string that you enter in the free text field of a grid filter is analyzed according
to the following set of rules:
Search
String
Search Result Logical
equivalent
Yellow card Searches for the words yellow and card in the
corresponding column.
“Yellow” AND
“card”
Yellow | card Searches for yellow or card in the
corresponding column.
“Yellow” OR
“card”
"Yellow card" Searches for exact matches of "Yellow card" in
the corresponding column. Between the quotes,
all characters are considered as characters and
not operators or wildcards.
”Yellow card”
card* Searches for “card” at the beginning of a word. “card”*
*card* Searches for all words that include “card”. *”card”*
11.5.3 HOW TO PERFORM A SEARCH THROUGH GRID FILTER FIELDS
To enter search values in the Grid Filter fields, proceed as follows:
1. Select the tree branch you wish to perform a search on.
2. Show the columns you wish to perform a search on.
3. Display the Grid Filter bar by clicking the Show/Hide Grid Filter Bar button
over the grid.
