Issue 5.9.B IPDirector Version 5.9
–
User Manual
–
Part 3
–
Browsing
EVS Broadcast Equipment – January 2011
98
Note
When the Search on All Columns option is activated, the search process
may be slower.
Important
If you perform a Search on all columns without having displayed all the
columns, you will not be able to identify in which column the search
string has been found. For the sake of clarity, it is recommended to
display all columns when you perform a Search on all columns.
QUICK TEXT SEARCH FIELD DISPLAY
The following table shows the various displays for the Quick Text Search field,
and what it means:
Display Meaning
The field background is white:
No Quick Text Search is entered
or applied or entered.
The field background is red:
The user is typing or has typed
a search string, but has not
applied it yet.
The field background is green:
The user has applied the search
string, by pressing ENTER. The
result of the Quick Text Search
is displayed in the grid.
The Quick Text Search field is
a combo box that gives access
to the previously searched
strings.
HOW TO PERFORM A QUICK TEXT SEARCH
To perform a Quick Text Search, proceed as follows:
1. Select the tree branch you wish to perform a quick search on.
2. Show the columns you wish to perform a quick search on.
3. Type a search string in the Quick Text Search field, based on Quick Text
search rules available from the Help button and detailed in section
‘Quick Text Search Rules’ on page 99.
