IPDirector Version 5.9
–
User Manual
–
Part 3: Browsing
EVS Broadcast Equipment – January 2011
Issue 5.9.B
89
9.12 LOG EVENT COLUMNS
The log event information is organized in columns in the Database Explorer grid.
The following table describes the contents of these columns:
Column Name Description
DEFAULT COLUMNS
T/C Timecode when the event was entered in the log.
Description Description of the event as entered upon creation.
Level A rating can be given to a log, from no stars to three stars.
This can be done at any time and can provide a useful search
criterion for use in the Database Explorer.
Color Colour given to the log at creation in IPLogger, if any.
Keywords The first five keywords associated with this log sheet.
Participants Participant keywords associated with this log sheet.
Parent
keywords
Keywords defined in the log sheet properties and therefore
common to all the logs of the log sheet.
Parent
Participants
Participant keywords defined in the log sheet properties and
therefore common to all the logs of the logsheet.
ADDITIONAL COLUMNS (alphabetically)
Log Date Date as defined when the log sheet was created.
Log LTC LTC timecode
Log LTC Date LTC date
Log USER T/C User timecode
Log USER T/C
Date
Date according to the user time code
Associated
Clips
The clips that contain the log T/C and that have been made on
the relevant recorders for the log sheet.
Event Name Name of the log sheets defined when it was created.
Event
Description
Free text entry, description added by user.
Event Date Date of the event for which the log was created.
Published User groups (if any) to which the log has been published.
