4. Do one of the following to define a swap or mute:
• For a swap, click in the matrix at the intersection between the source
channel to play and the output channel on which the source should be
played.
• For a mute, click in the matrix on the bullet located on the line of the
output channel to mute.
5. If you want to apply the swap between a mark IN and mark OUT points, tick
the Apply between mark IN and mark OUT check box.
In this case, you can overwrite existing swap/mute between these points by
ticking the Overwrite existing swap/mute check box.
6. If you want to define a mix effect at the start and end of the swap, specify the
duration of the effect in the Swap mix duration spin box.
7. Click Apply.
The swap and mutes are defined on the requested part of the audio track.
This is symbolized with the swap icon or the mute icon displayed on the
relevant elements in the general display of the timeline.
The swaps and mutes can be viewed on the Swap/Mute Zoom display:
4.13.9 MODIFYING AUDIO SWAPS
HOW TO MODIFY A SWAP OR MUTE ON ONE OR MORE
ELEMENTS OF AN AUDIO TRACK
To modify a swap or mute defined on one or more elements of an audio track,
proceed as follows:
1. In the general timeline display, select the elements of a track on which you
want to modify the swap. For a multiple selection, select the elements while
pressing CTRL.
2. Right-click one of the selected elements and select Modify Swap/Mute.
The Swap/Mute Configuration window opens with the parameters defined on
the first swapped element of the selection.
