Issue 5.8.B IPDirector V.5.8
–
User Manual
–
Part 7: Editing -
IPEdit
EVS Broadcast Equipment - July 2010
92
Edit Type Points/Marks
in Player
Marks in Timeline Element Position
3-point
edit
- - IN OUT Nowline
on mark IN
Blue indicator of media
positioned on mark IN of
timeline + calculation of
the mark OUT point of
inserted media
3-point
edit
- - IN OUT Nowline
on mark
OUT
Blue indicator positioned
on mark OUT of timeline
+ calculation of the mark
IN point of inserted
media
4-point
edit
IN OUT IN OUT Nowline Media between marks in
the Player added
between mark IN and
mark OUT points in the
timeline + speed is
automatically calculated
in the timeline
4-point
edit
IN OUT IN - Nowline
after mark
IN
Equivalent to a 4-point
edit since the nowline
acts as a mark OUT.
4-point
edit
IN OUT - OUT Nowline
before
mark OUT
Equivalent to a 4-point
edit since the nowline
acts as a mark IN.
4.5.4 ADDING MEDIA IN INSERT OR OVERWRITE USING DRAG-AND-
D
ROP ACTIONS
Dragging media to the timeline does not directly determine whether the media will
be inserted or overwritten in the timeline. The Insert or Overwrite mode defined in
the timeline is taken into account for drag-and-drop actions.
DRAG MEDIA FROM THE PLAYER IN THE TIMELINE
To add media to a timeline by dragging it from the Player to the timeline, proceed
as follows:
1. In the Timeline pane, select the Insertion mode with the Insert/Overwrite
Toggle icon in the Edit Command bar.
2. In the loaded timeline, do one of the following to define the insertion
position if you do not want to add the media on an element transition:
a. Position the nowline
b. Add a mark IN or mark OUT point
