Issue 5.8.B IPDirector Version 5.8
–
User Manual
–
Part 5: Playout
–
Player Control Panel
EVS Broadcast Equipment – July 2010
62
When a XT hi-res clip is not present in the clip, the Save Clip window will be
displayed as follows:
In all cases, the Save Clip window is divided into two panes:
• The left pane contains the Clip Information, i.e. clip data in general and in
relation with IPDirector.
It is always displayed.
• The right pane contains the Clip Metadata, i.e. clip data based on customer-
specific fields.
Clicking the right area in the Pane Display icon will display this right
pane.
Later Access to the Data
Once the clip has been saved, the data will be available in the Clip Information tab
and the Metadata tab of the Control Panel. Most of this data can be edited directly
from these tabs.
FIELDS IN THE SAVE CLIP WINDOW
The following table describes briefly the data that can be added to clips.
The Clip Information pane contains the following fields:
Field Description
LSM ID LSM ID, i.e. location where the clip will be stored on the XNet
network. This numbering is based on the numbering of the LSM
operational mode.
Tape ID This identifies the tape on which the clip is stored.
