IPDirector Version 5.8
–
User Manual
–
Part 5: Playout
–
Player Control Panel
EVS Broadcast Equipment – July 2010
Issue 5.8.B
57
HOW TO LOAD A PLAYLIST BY A DRAG-AND-DROP ACTION
To load the playlist via the Database Explorer proceed as follows:
1. Open the Database Explorer from the main menu.
2. Select the requested playlist in the element list of the Explorer.
3. Drag it onto the top part
of the Clip-List tab of the Control Panel.
Note
Dragging it into the clip-list grid would insert the playlist into
the previously loaded one.
The playlist will then be loaded on the IN point of the first element.
If another playlist had previously been loaded, this latter is replaced by the new
one on the Playlist Panel.
1.4.5 TAKE FUNCTION IN PGM/PRV MODE
+
If the channel is in PGM/PRV mode, the Take function shifts from the current
media on the PGM channel to the media on the associated PRV channel using the
Take Effect settings as defined in Tools > Settings > Clips > Clips/Take.
If a clip is loaded on the PGM channel and a train is being played on the PRV
channel, the Take function will load the train on the PGM channel and the clip on
the PRV channel.
Refer to section Settings in part 1 of the user manual for more information on the
Take settings. This function is only available from a shortcut.
