IPDirector Version 5.8
–
User Manual
–
Part 5: Playout
–
Player Control Panel
EVS Broadcast Equipment – July 2010
Issue 5.8.B
55
rules apply:
1. lo-res clip
2. lo-res file
3. hi-res clip
4. hi-res file
1.4.3 LOADING A PLAYLIST ELEMENT ONTO THE CONTROL PANEL
INTRODUCTION
When a playlist element is drag and dropped on a control panel, the panel is
automatically associated to the playlist panel from which the element comes from.
The Channel field will turns light blue in both Control Panel and Playlist Panel
windows.
The title bar and the window frame background color for both panels will remain
orange for the active window and will turn light blue for the inactive window,
indicating that a playlist element is loaded on a Control Panel.
The Playlist Panel is dimmed but it is possible to play the element from the
Control Panel and trim it, if required, as described in section 1.7.3 ‘How to Edit a
C
lip Duration’ on page66.
HOW TO LOAD A PLAYLIST ELEMENT ONTO THE CONTROL
PANEL
It is possible to load a playlist element onto the Control Panel. To do so, proceed
as follows:
1. Open the Control Panel.
2. Open a playlist in the Playlist Panel interface.
3. Drag an element from the playlist onto the Control Panel.
The element will then be loaded on the Control Panel.
