Issue 5.8.B IPDirector Version 5.8
–
User Manual
–
Part 5: Playout
–
Player Control Panel
EVS Broadcast Equipment – July 2010
32
CREATION DATE
The Creation Date is a read-only field that displays the date and time when the
clip has been created.
PUBLISHED TO CHECK BOXES
The Published To check boxes indicate to which user groups the clip is published,
i.e. available for view or changes depending on the user rights.
All user groups defined in the User Manager application are displayed in the
Publish To check boxes. The clip is published to the user groups for which the
check box is selected. Only the users who belong to one of the selected groups
and have visibility rights on clips will be able to view the clip.
For more information on how to publish a clip to a user group, refer to section
1.10.1 “How to Publish a Clip to a User Group”, on page 73.
LINKED TO CLIPS LIST
The Linked to Clips List displays the clips linked to the loaded clip.
Clips can be linked to another clip in two ways:
• When a clip is created on a channel ganged to other channels, the clips created
simultaneously on the ganged channels will automatically be linked to the clip.
• When a user manually links a clip to another one. To link two or more clips
together, you need to select them in the Database Explorer and choose Link
from the contextual menu.
Double-clicking a linked clip will load it on the Control Panel.
Right-clicking the linked clip will display a contextual menu that is related to the
linked clip (not to the loaded clip).
