IPDirector Version 5.8
–
User Manual
–
Part 5: Playout
–
Player Control Panel
EVS Broadcast Equipment – July 2010
Issue 5.8.B
19
Play/Pause Position Indicator Duration Value Color
Pause Before IN point Duration to the IN point Grey
Play Before IN point Count down of the
remaining time to the
OUT point
Grey
Pause After OUT point Duration from the OUT
point
Grey
Play After OUT point Count down of the
remaining time to the
end of guardband
(Protect OUT point)
Grey
When a record train is loaded
The following table shows the possible colors and values of the Right Duration
field when a train is loaded.
The Right Duration field value and color depends on:
• whether the train is playing or paused
• whether an IN and/or OUT points are defined
• the media position indicator.
Play/Pause IN/OUT Point Position
Indicator
Duration Value Color
Play/Pause No IN, no OUT On current
timecode
Recording
capacity left on
the train
Blue
Play/Pause No IN, no OUT Before current
timecode
Delay time from
current
timecode
Yellow
Play/Pause Only IN defined Before IN point Duration to IN
point
Grey
Play/Pause Only IN defined After IN point Duration from
IN point
Yellow
Play/Pause Only OUT defined
Before OUT
point
Duration to
OUT point
Yellow
Play/Pause Only OUT defined
After OUT
point
Duration from
OUT point
Grey
Play/Pause IN and OUT
defined
Before IN point Duration to IN
point
Grey
Pause IN and OUT Between IN Duration
between IN and
Yellow
