Issue 5.8.B IPDirector Version 5.8
–
User Manual
–
Part 5: Playout
–
Player Control Panel
EVS Broadcast Equipment – July 2010
18
1. Left Timecode field
2. Right Duration field
3. Play Mode button
LEFT TIMECODE FIELD
The Left Timecode field shows the current timecode for the material being
controlled by the panel:
• If a record train is loaded, the field shows the timecode of the record train.
• If a clip, file or a playlist is loaded, the field shows the current timecode
position of the element.
The following display options are available. They can be changed by right-clicking
on the Left Timecode field.
• Timecode only
• Timecode and date
• Timecode and date and TC type (LTC or user)
• Timecode and TC type
When the TC type is displayed, right-clicking on it permits to shift from one type to
the other (LTC or user).
RIGHT DURATION FIELD
The Right Duration field will have a different meaning and display color according
to the activity being performed on the channel.
When a clip is loaded
The following table shows the possible colors and values of the right duration
field when a clip is loaded.
The right duration field value and color depends on:
• whether the clip is playing or paused
• the media position indicator.
Play/Pause Position Indicator Duration Value Color
Pause On or between IN
and OUT points
Duration to the OUT
point
Yellow
Play On or between IN
and OUT points
Count down to the OUT
point
Yellow
