IPDirector Version 5.8
–
User Manual
–
Part 5: Playout
–
Player Control Panel
EVS Broadcast Equipment – July 2010
Issue 5.8.B
15
The 2
nd
Controller option is only available if the channel has been configured with
the IPDP protocol as the main controller in exclusive mode.
When the configuration has been set to parallel mode the control of the channel is
from either IPDirector or the 3
rd
Party device simultaneously and the second
control feature is inactive.
Note
To configure which protocol and port each channel can be controlled by,
see the chapter ‘Connection to EVS Video Server’ in the Technical
Reference manual.
PANE DISPLAY ICON
This icon makes it possible to display or hide the various window panes. The
hidden panes are grey-coloured and the displayed panes are orange-coloured.
You can display the various panes as follows:
Pane to be displayed Required Action
To display the Minimal view
Click the upper left icon
To display the Transport
Functions view
Click the middle left icon:
To display the
Clip Creation view Click the bottom left icon:
To display the
Full view Click one of the right icons:
