2.3.2 DISPLAY OPTIONS
Through the Display Options menu, you can configure which recorder channels
and/or streams to display. The various menu items of the Display Options menu
are detailed in the tables below:
Selected Menu Item
Recorders / streams displayed
hi-res
recorders
hi-res
streams
lo-res
recorders
lo-res
streams
No selection X
Recorder LoRes X X
Streams HiRes X X
Streams LoRes X X X
Menu Item Description
Off-line
Channels
Displays or hides off-line recorder channels, i.e. recorder
channels available based on the EVS video server setup but
not used.
Selected only Displays the recorder channels for which the checkbox at the
left of the recorder name has been selected.
My Schedules
only
Displays only the scheduled blocks created by this user.
Show
categories
Displays only the blocks corresponding to the selected
categories. A sub-menu allows the user to select a single
option between the following: All categories, No category, or
the different categories defined. For more information on where
to define ingest block categories, see the section ‘Fields in the
N
ew Schedule window’ on page 30.
