Issue 4.3.C
IP Director Version 4.3 – User Manual – Part 2 – Logging and Browsing
EVS Broadcast Equipment
86
contain one of the defined values, i.e. one of the defined
keywords, will fulfil the criterion. This principle is also valid
for the Status, Owner and Recorder fields.
• When several criteria are defined in a bin rule, the clips
should meet at least one value in each of the defined
criteria to match the bin rule. All rules are therefore an
‘AND’ form of searching, and cannot be performed as an ‘OR’
search.
CREATION DATE
The Creation Date criterion allows specifying a date interval OR
a number of days back in the past. The clips that have been
created within the given date interval or within the number of
days specified will meet the criterion on the Creation Date.
Since the bin rule is only applied on the clips created after the
bin rule definition, you should take the following remarks into
account:
• If you select a Creation Date criterion based on a date
interval, select a date interval in the future.
• If you select a Creation Date criterion based on the last 2
days, for example, the new clips will only be checked against
the bin rule two days after the bin rule has been defined.
To specify a creation date criterion, proceed as follows:
1. Select the ‘date interval’ or ‘last x days’ value from the left
drop-down list
2. Select a From data and To date or a number of days from the
drop-down lists, depending on the value selected in the left
field.
INTEREST LEVEL
The Interest Level criterion allows specifying an interest level or
a minimum interest level. The clips to which one of the selected
interest levels is assigned will meet the criterion on the Interest
Level.
To specify that clips with a given interest level should be taken
into account, select the corresponding interest level icon.
To specify that clips with at least a given interest level should be
taken into account, select the lowest interest level to be taken
into account and click the
icon. The higher interest levels
will be selected.
