IP Director Version 4.3 – User Manual – Part 2: Logging and Browsing
EVS Broadcast Equipment
Issue 4.3.C
85
CRITERIA OVERVIEW
Different criteria are available depending on the element, i.e.
clip or play-list, on which you want to specify bin rules. The
following table provides an overview of the available criteria and
indicates on which element they can be defined:
Field Criteria based on the … Clip Play
-List
Creation
Date
Date when the element has been
created.
√ √
Interest
Level
Interest level defined on the clip.
√
T/C Time code interval in which the clip
has been created.
√
Status Status associated with the clip.
√
Type Type associated with the clip.
√
Keyword Keywords assigned to the clip.
√
Owner Owner of the clip.
√ √
Recorder
s
Recorders on which the clip has
been created.
√ -
XT
Servers
XT Servers on which the play-list is
located.
- √
PRINCIPLES FOR CRITERIA DEFINITION
The following principles are applicable in the Bin Rules window:
• When you click a top icon corresponding to a criterion, e.g.
, an empty record corresponding to this criterion
is added in the tab:
This allows the user to specify search values for this
criterion.
• If you click again on a top button after specifying values in a
related record, the record is hidden. The values defined in
hidden records are stored until the rule is saved. The values
defined in hidden records will be lost with the save action.
• When an icon is selected in one of the criteria, it is
highlighted in green.
• For several criteria, you can specify more than one value
within a record, e.g. for the keyword criterion. The clips that
