Issue 4.3.C
IP Director Version 4.3 – User Manual – Part 2 – Logging and Browsing
EVS Broadcast Equipment
76
Command Description
them can be deleted.
For more information, see the section “How
to Delete Unused Play-Lists” in the Play-List
Editor chapter, part 3 of this user manual.
Rename Opens the Enter a New Play-List Name
window in which the users can modify the
name of the play-list selected in the element
list.
Set as default
play-list
Allows the users to set the selected play-list
as default play-list.
Create a new
off-line play-
list in the
default bin
Creates a new empty on-line play-list in the
current bin (i.e. the bin selected in the Mini
Database Explorer) or in the default bin,
depending on the selected command.
The user has to specify the play-list name
before the new play-list is created. The play-
list is automatically loaded in the selected
play-list tab.
Create an off-
line copy
Creates a new off-line play-list in the default
bin (only option available in the element
list).
This new off-line play-list has the same
content as the play-list selected. It also has
the same name, preceded by an underscore.
Create an on-
line copy
Creates a new on-line play-list in the default
bin (only option available in the element
list). Before creating the play-list, the
operator selects the XT on which it will be
created.
This new on-line play-list has the same
content as the play-list selected. It also has
the same name, preceded by an underscore.
Make the play-
list on-line
Turns an off-line play-list into an on-line
play-list by storing it on a given location on
an XT server. An LSM ID is assigned to the
on-line play-list.
Copy play-list
clips locally
Copies the distant clips of the selected play-
list to the local XT, i.e. the XT on which the
play-list is created.
The clips are physically copied to the local
XT and their new LSM ID is displayed in the
element list. The Status icon changes from
to .
Properties Displays information related to the owner
and the groups the open play-list has been
