Issue 4.3.C
IP Director Version 4.3 – User Manual – Part 2 – Logging and Browsing
EVS Broadcast Equipment
62
3.2.9 HOW TO SEND A CLIP TO A DESTINATION
FOLDER (DESTINATION TARGET)
To send a clip to a destination folder, proceed as follows:
• Select a predefined destination directory (target) from the
Send To sub menu of the clip contextual menu.
The destination folder can be located anywhere on the IP
network. This gives full flexibility to directly send A/V files to
third party systems (i.e. NLE systems) and storage paths.
3.2.10 HOW TO ADD A DESTINATION TARGET
To add a destination target to the list, proceed as follows:
1. Select the Add Archive Target option from the Send To
sub menu.
The New Archive Target window opens.
2. Fill in the field in the New Archive Target window.
For more information on the fields, refer to section 3.2.11
“New Archive Target Window”, on page 62.
3. Se
lect OK.
The new destination target is added to the list of destination
targets in the contextual menu.
3.2.11 NEW ARCHIVE TARGET WINDOW
The New Archive Target window makes it possible to add a new
destination or archive target. The fields displayed on the Archive
Target Window are described below:
Field Description
Alias The name of the target as it will appear in the
contextual menu.
