Issue 4.3.C
IP Director Version 4.3 – User Manual – Part 2 – Logging and Browsing
EVS Broadcast Equipment
56
Command Description
Import a play-
list …
Not relevant in the element list.
Publish Opens the Publish Clip window from which
the selected clip can be published, i.e. made
available, to selected groups of users.
See also the section 3.2.18.
Delete Deletes the selected clip from the XT
Server.
View Key Clip Displays the Key clip associated with a Fill
clip that is selected. This option is only
active on Fill clips that are included in a Fill
and Key association.
Delete Fill and
Key Link
Deletes the link between the Fill and Key
clips. This option is only active on Fill clips
that are included in a Fill and Key
association.
Edit Opens the Edit Clip window from which the
user can modify the clip information.
See also the section 3.2.6.
Modify T/C IN
or Date
Opens the Modify T/C In or Date window
from which the user can modify the IN
timecode or date of a clip.
See also the section 3.2.17.
Duplicate Opens a Duplicate Clip window where the
user can specify the location on an XT
server of the XNet Network where a copy of
the clip should be stored.
See also
Move Opens a Move Clip window where the user
can specify the location on an XT server of
the XNet Network where the clip should be
moved to.
Link Allows the user to link selected clips
manually together. It is only possible to link
clips that are not already associated with
other clips.
Unlink Allows the user to unlink the clips linked to
the selected clips.
View Clip
Status History
Opens the Status and History window from
which the user can view the history of all
transfers of the selected clip.
